Description
| range of product |
Altivar Process ATV900
|
|
|---|---|---|
| product or component type |
Variable speed drive
|
|
| device application |
Industrial application
|
|
| device short name |
ATV930
|
|
| variant |
Standard version
With braking chopper |
|
| product destination |
Asynchronous motors
Synchronous motors |
|
| mounting mode |
Wall mount
|
|
| EMC filter |
Without EMC filter
|
|
| IP degree of protection |
IP21 conforming to IEC 61800-5-1
IP21 conforming to IEC 60529 |
|
| degree of protection |
UL type 1 conforming to UL 508C
|
|
| type of cooling |
Forced convection
|
|
| supply frequency |
50…60 Hz (+/- 5 %)
|
|
| network number of phases |
3 phases
|
|
| [Us] rated supply voltage |
200…240 V (- 15…10 %)
|
|
| motor power kW |
0.75 kW (normal duty)
0.37 kW (heavy duty) |
|
| motor power hp |
1 hp (normal duty)
0.5 hp (heavy duty) |
|
| line current |
3 A at 200 V (normal duty)
2.6 A at 240 V (normal duty) 1.7 A at 200 V (heavy duty) 1.5 A at 240 V (heavy duty) |
|
| prospective line Isc |
50 kA
|
|
| apparent power |
1.1 kVA at 240 V (normal duty)
0.6 kVA at 240 V (heavy duty) |
|
| continuous output current |
4.6 A at 4 kHz (normal duty)
3.3 A at 4 kHz (heavy duty) |
|
| maximum transient current |
5.5 A during 60 s (normal duty)
5 A during 60 s (heavy duty) |
|
| asynchronous motor control profile |
Constant torque standard
Variable torque standard Optimized torque mode |
|
| synchronous motor control profile |
Permanent magnet motor
|
|
| speed drive output frequency |
0.1…599 Hz
|
|
| nominal switching frequency |
4 kHz
|
|
| switching frequency |
2…16 kHz adjustable
4…16 kHz with derating factor |
|
| safety function |
STO (safe torque off) SIL 3
|
|
| discrete input logic |
16 preset speeds
|
|
| communication port protocol |
Ethernet/IP
Modbus serial Modbus TCP |
|
| option card |
Slot A : communication module for Profibus DP V1
Slot A : communication module for Profinet Slot A : communication module for DeviceNet Slot A : communication module for CANopen daisy chain RJ45 Slot A : communication module for CANopen SUB-D 9 Slot A : communication module for CANopen screw terminals Slot A : communication module for EtherCAT Slot A/slot B/slot C : digital and analog I/O extension module Slot A/slot B/slot C : output relay extension module Slot B : 5/12 V digital encoder interface module Slot B : analog encoder interface module Slot B : resolver encoder interface module |
For more information about the product please click HERE
