OPTIFLEX 6200

The OPTIFLEX 6200 is a 2-wire guided radar level transmitter based on the Time Domain Reflectometry (TDR) technology. It is designed for the level measurement of solids in bulk storage and other silos up to a height of 40 m / 131.2 ft. The single rod or single cable probes withstand high traction loads, making the level transmitter suitable for use in a wide range of applications with solids of different grain sizes – from fly ash and cement to gypsum and plastic granulates to tobacco and starch. This guided radar is equally suitable for applications involving milk, chocolate or coffee powder.

The OPTIFLEX 6200 is insensitive to dusty atmospheres or deposits on the probe. For applications that are difficult to access, a transmitter version with remote converter can be installed 100 m / 328 ft away from the probe. The converter comes with aluminium or stainless steel housing and is compatible with previous KROHNE TDR generations.

Product highlights

• Specific algorithm for low-reflective media
• Designed to withstand high traction loads (<3.6 t)
• Various converter and electronic versions to facilitate access to the device:
  • Remote version up to 100 m / 328.08 ft
  • Horizontal or vertical housing to suit every installation
• Quick coupling system: converter is rotatable and removable under process conditions
• Converter compatible with all process connections from previous KROHNE TDR models
• ESD protection (24 kV) for increased resistance to electrostatic discharges
• Weather protection – protects the converter in extreme weather events
• Stainless-steel housing for corrosive environments
• ±2 mm / ±0.08″ accuracy
• SIL 2/3 (in preparation)

Typical applications

General

• Level measurement of solids in buffer silos, bulk storage containers, hoppers etc.

Chemical industry

• Plastic granulates (PPC, PVC, PE, LDPE, PP)
• Soap powder

Food and beverage industry

• Agri foods (tobacco, starch)
• Milk powder, coffee powder, chocolate powder

Metals industry, minerals and mining industry

• Hydrate lime, silica, gypsum, fly ash
• Other fine powders (cement, alumina etc.)
